What is a Tapped line in electrical systems?

A tapped line, in the simplest terms, is an electrical line that has one or more connection points, or ‘taps’, along its length. These taps allow for the connection of loads at various points along the line, rather than just at the ends. Simply put, it’s a secondary power line created by connecting to an existing, larger transmission or distribution line.

The primary function of a tapped line is to provide flexibility in the distribution of electrical power. By allowing for connections at various points along the line, power can be distributed to multiple loads from a single source. This can be particularly useful in situations where loads are spread out over a large area, such as in a residential neighborhood or an industrial complex.

Tapped lines find extensive applications in power distribution systems. For instance, in a residential power distribution system, a tapped line might run along a street, with individual taps providing power to each house. Similarly, in an industrial setting, a tapped line could distribute power to various pieces of machinery or equipment spread out across a factory floor.


  • Enhanced flexibility: They allow for targeted electricity delivery to specific communities, industrial installations, or even individual buildings, reducing the need for additional, dedicated overhead or underground lines. This saves cost and minimizes environmental impact.
  • Improved grid resilience: Tapped lines provide redundancy in the system. If a segment of the mainline experiences a fault, tapped lines can continue supplying power to critical areas, minimizing outages and ensuring uninterrupted service.
  • Optimized voltage management: Tapped lines can help regulate voltage levels by drawing off and redirecting power. This prevents voltage fluctuations at distant consumers, ensuring a consistent, reliable power supply.
  • Efficient power distribution: In rural areas with scattered communities, tapped lines can effectively bridge the gap between major transmission lines and remote consumers. This allows for cost-effective electrification without requiring extensive, long-distance primary lines.

Few considerations,

  • Design complexity: Tapping into existing lines requires careful planning and specialized equipment to ensure smooth integration and prevent disruptions.
  • Load limitations: Tapped lines inherit capacity limitations from the main line. Overloading them can lead to voltage drops, equipment damage, and even safety hazards.
  • Maintenance challenges: The connection points require regular inspection and maintenance to ensure reliable operation and prevent potential safety issues.
